40FT & 48FT CURTAINSIDE 20FT & 40FT TRANSIFLATS

OVERVIEW OVERVIEW INTERMODAL & FREIGHT

The Royal Wolf 40ft heavy weight and 48ft leight weight • Fixed or movable roof supports Royal Wolf design, test and manufacture Optional Features Include:
and heavy weight curtainside containers are the units • Recessed tie down points transiflats to suit your operational
of choice for leading transport companies. They are • Mezzanine decks requirements. Transiflats are intermodal so • Checker plate steel floor
fully intermodal, meaning they can be top lifted and are that they can be used to carry freight on road,
suitable for loading a wide range of freight. • Recessed curtain buckles to reduce rail or sea. Side end gates can be customised • Customised side/end gates
maintenance costs
The side access which curtain sides offer, depending on the freight profile. • Full length tie rails
allow ease of loading and unloading of both • Suspended gate system and sliding load Transiflats can be nested when empty • Load binders
palletised and overlength cargo. binders therefore reducing transport costs. • Recessed tool box
• Tool box, alloy tensioners
Optional Features Include: • Customised branded curtains
• Load binder winches and straps • Corrugated roof for added strength
DIMENSIONS (mm)
CONTAINER EXTERNAL INTERNAL WEIGHT (kg) CAPACITY
Length Width Height Length Width Height Max. Gross Tare Payload M3
40ft x 2500 x 9’6”
HD Curtainside 12192 2502 2896 11887 2446* 2497 35000 6510 28490 72.5
40ft x 2500
x 9’10” HD 12192 2502 2997 11887 2446* 2598 35000 6560 28440 75.5
Curtainside
48ft x 2500 x
9’10” Lightweight 14746 2500 3000 32000 8680 23320 92.1
Double Stack
Curtainside
DIMENSIONS (mm)
48ft x 2500 x 9’10” 1247/12018/ 1199/2444 WEIGHT (kg)
HD Single Stack 14746 2500 3000 1247 /1199 2644 32000 7770 24230 92.9 CONTAINER EXTERNAL INTERNAL
Curtainside LENGTH WIDTH HEIGHT LENGTH WIDTH HEIGHT MAX. GROSS TARE PAYLOAD
48ft x 2500 x 9’10” 1245/3570/ 1195/1195/2444/ 20ft Transiflat 6058 2500 236 6058 2500 N/A 30480 2200 28280
HD Double Stack 14746 2500 3000 4760/3570/1245 1195/1195 2596 35000 9390 25610 90
Curtainside 40ft x 2500 Transiflat 12230 2500 250 12230 2500 N/A 32000 3900 28100
* Internal width between roof supports 2376mm
